Maximum measurement of continuous DC current IPN DC: ±200A
Maximum measurement of continuous RMS current IPN: 140A
Measure the current range IPM(DC): ±240A
Current transfer ratio KN: 1000:1
Output current IS: ±200mA
Precision (DC): 10ppm
Bandwidth BW(±3dB): 300kHz
Maximum overload capacity @ single pulse 100ms: ±240A
Power supply voltage: ±15V
Power consumption (IPwr): ±220mA
Maximum measuring aperture: 30mm
Secondary interface: DB9
