Pintech THS6102 Portable Oscilloscope (100MHz, 1GS/s)

Bandwidth: DC-100MHz

Sample rate: 1GS/s

Rise time（BNC typical）: ≤3.5ns

Storage Depth: up to 6000 points per channel

Channel: dual-channel

Input coupling: DC, AC, GND

Input impedance: 1MΩ±2%，and 20pF±5pF parallel

Time base accuracy: 5ns/div~100s/div，step according to 1～2～5 base system

Vertical sensitivity: 5mV/div~5V/div(at input)

Vertical resolution: 8bit

Input Voltage: 400V （DC AC peak, 1MΩ input impedance) （10：1 probe attenuation）

Trigger mode: Auto, Normal, and Single

DC gain accuracy: ±3%

Waveform storage: 4 waveforms

Cursor measurement: Voltage difference between cursors △V, Time difference between cursors △T

USB flash drive copy function: Yes

Standard Interface: USB

Partial performance parameters of multimeter:

Digital display: 3 digits (display 4000)

Input Impedance: 1MΩ

Voltage:

VDC : 400mV, 4V, 40V, 400V, 1000V : ±(1% ± 2 words); input voltage : DC 1000V

VAC : 4V, 40V, 400V : ±(1% ± 3 words), 750V : ±(2% ± 3 words);

Frequency range : 40Hz - 400Hz; input voltage : AC 750V RMS

Current:

DC : 40mA, 400mA : ±(1.5% ± 1 word), 10A : ±(3% ± 3 words)

AC : 40mA : ±(1.5% ± 3 words), 400mA : ±(2% ± 1 word), 10A : ±(5% ± 3 words)

Resistance: 400Ω : ±(1% ± 3 words), 40ΚΩ - 4ΜΩ : ±(1% ± 1 word), 40MΩ : ±(1.5% ± 3 words)

Capacitance: 51.2nF - 100uF : ±(3% ± 3 words)

Diode: Voltage readings0V~1.5V

Continulty test: Judgment resistance <50Ω （±30Ω）（beep）
