INPUT
Phase: 1Ø / 2 Wire + G
Voltage: 196-264VAC (opt. 175-235VAC)
Frequency: 47 Hz - 63 Hz (opt. 400Hz)
Max. Current: 40A
OUTPUT
Power: 5000VA -4000W
Phase: 1Ø / 2 Wire + G
Voltage Ranges: 0 - 155Vrms / 0 - 310Vrms, user selectable
Voltage Accuracy: ± (0.5 % of setting + 0.1% F.S.)
Voltage Resolution: 0.1Vrms
Frequency: 5-2000Hz
Frequency Accuracy: ±0.02%
Frequency Resolution: 0.1Hz, 1Hz
Max. Current (RMS): 40A / 20A
Max. Current (Peak): 180A / 90A
Total Harmonic Distortion (THD): ≦0.3% at 40-100Hz, ≦0.5% at 101-500Hz, ≦0.8% at 501-1000Hz (Resistive Load)
Line Regulation: ± 0.1V
Load Regulation: ≦0.07% F.S. (Resistive Load)
Response Time: ≦ 300uS
Crest Factor: ≧ 3
Inrush Current: ≧ 4.5 times of max. output current (r.m.s)
DC OUTPUT
Power: 4000W
Voltage Ranges: 0 - 210V / 0 – 420V
Max. Current: 20A / 10A
Ripple & Noise (RMS): ≦ 0.24%
MEASUREMENT
Voltage Range: 0 - 420Vrms
Voltage Accuracy: ±(0.2% of reading + 5 counts)
Voltage Resolution: 0.1V
Frequency Range: 5- 2000Hz
Frequency Accuracy: ±0.1Hz at 5.0 - 500Hz, ±0.2Hz at 501 - 2000Hz
Frequency Resolution: 0.1Hz
Current Range: Hi: 0.05A - 48.00A
Current Accuracy: ±(1% of reading + 5 counts) at 5.0 - 500Hz, ±(1% of reading + 10 counts) at 501 - 2000Hz
Current Resolution: Hi: 0.01A
Peak Current Range: 0 - 180A
Peak Current Accuracy: ± ( 1% F.S.+ 5 counts )
Peak Current Resolution: 0.1A
Power Range: Hi: 0 - 4800W
Power Accuracy: ±(2% of reading + 10 counts) @ 5 - 500Hz, ±(2% of reading + 15 counts) @ 501 - 2000Hz
Power Resolution: Hi: 1W
GENERAL
Efficiency: ≧ 80% at max. power
Protection: OVP, OCP, LVP, OPP, OTP, RCP, Fan Fail
Remote Interface: Standard: RS232 / RS485 / Ethernet / USB / PLC Remote In&Out, Optional: GPIB / Analog Control
Over Current Foldback: CC Mode (Constant Current)
Output Sync Signal: ON, Event for Voltage or Frequency Change (Output signal 5V , BNC type)
Memories: 50 Memories & 1200 Steps (24 Steps/Memory); 50 Memories, 4 Hot keys (The last hot key can be adjusted)
Operating Temperature: 0˚C - 40˚C
Dimensions (HxWxD): 176 x 442 x 665mm
Weight: approx. 61.5 kg
