INPUT
Phase: 3Ø / 3 Wire + G
Voltage*1: 380V±15%
Frequency: 47-63Hz
Max. Current*2: 117.4A
Power Factor: ≥0.99(Max. Power)
OUTPUT
Power (VA:) 60kVA
Phase: 3Ø / 4 Wire + G
Voltage Ranges PFV Series: Low(V): 0V-150.0V(L-N); High(V): 0V-300.0V(L-N)
Voltage Ranges PAS-F Series: 0V-300.0V(L-N)
Voltage Resolution: 0.1V
Voltage Accuracy: 0.15% F.S.+4 counts
Frequency Range: Standard : 45-65Hz Option : 40-70Hz
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.1% F.S
Max. Current (RMS) PFV Series: Low(A): 166.7A; High(A) 83.3A
Max.Current(RMS) PAS-F Series: 83.3A
Line Regulation: ≤ 1%
Load Regulation: ≤ 1% (Resistive Load)
Total Harmonic istortion(THD): ≤ 2% (Resistive Load)
Response Time: ≤ 2ms
Crest Factor :≥ 3
MEASUREMENT
Voltage Range: 0V-300.0V
Voltage Resolution: 0.1V
Voltage Accurac:y 0.1%F.S.+2counts
Frequency Range: Standard : 45 ~ 65Hz Option : 40-70Hz
Frequency Resolution: 0.01Hz
Frequency Accuracy: ±0.01% F.S
Current Range(RMS): 0-9999A
Current Resolution(RMS): 0.1A
Current Accuracy(RMS): 0.1% F.S.+2 counts
Power Range: 0-1000kW
Power Resolution: 0.1kW
Power Accuracy: 0.2% F.S.+2 counts
GENERAL
Regenerative Function: YES
Low Voltage Ride Through(LVRT); High Voltage Ride Through(HVRT): NO
Three-phase independent adjustment: YES
Phase Angle Setting:YES
Efficiency: ≥ 92% at Max. Power
HMI: Touch Screen: 7" Color TFT LCD
Remote Interface: Standard : RS-485, RS-232 Option : GPIB, Ethernet, USB
Operating Temperature: 0ºC ~ 45ºC
Humidity: 0~90% ( Non condensing )
Altitude: < 1,500m
Dimensions (H x W x D)*3: 2200 x 1200 x 800mm /86.61x 47.24 x31.49 inch
Weight: 1150kg/ 2530lbs
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V.
*3 Including wheels.
* All specifications are subject to change without notice.
