Power: 150Wx2
Current: 0~1.5A: 0~6A
Voltage: 0~500V
Min.Operation Voltage: 4V@6A
-CC mode
+Range: 0~1.5A; 0~6A
+Resolution: 0.025mA; 0.1mA
+Accuracy: 0.1%
-CR mode
+Range: CRL: 1Ω~3KΩ (300V); CRH: 2Ω~6KΩ (500V)
+Resolution: 16.666µS; 8.333µS
+Accuracy: ±0.2%
-CV mode
+Range: 60V/300V/500V
+Resolution: 0.001V/0.005V/0.01V
+Accuracy: ±0.05%
-CP mode
+Range: NA
+Resolution: NA
+Accuracy: NA
-LED mode
+Vo Voltage range: LEDL:60V/LEDM:300V/LEDH:500V
+Rd Resistance range: LEDL:1~200Ω@Vo-Vd=0~6V
LEDL:10~2KΩ@Vo-Vd=6~60V
LEDM:5~1KΩ@Vo-Vd=0~30V
LEDM:50~10KΩ@Vo-Vd=30~300V
LEDH:10~2KΩ@Vo-Vd=0~60V
LEDH:100~20KΩ@Vo-Vd=60~500V
+Resolution: 16 bits
+Accuracy: Vd: ±(0.05% of setting + 0.1% of range); Rd: ±(0.05% of setting + 0.1% of range)
- Option (necessary) : 3302F- single channel mainframe ; 3305F- two channels mainframe ; 3300F- four channels mainframe
- Optional interface : GPIB, RS232, USB, LAN
