Input voltage:
110 VAC ~ 127 VAC x 10 % / 60 Hz
220 VAC ~ 240 VAC x 10 % / 50 Hz (switchable)
Output voltage: 2 x 0 to 30 V
Output current: 0 to 5 A
Line regulation:
Two adjustable output:
CV = 1 x 10 -4 + 3 mV
CC = 2 x 10 -3 + 3 mA
Fixed output: 10 mV
Load regulation:
Two adjustable outputs:
CV = 1 x 10-4 + 2 mV
CV = 1 x 10-4 + 5 mV
CC = 2 x 10-3 + 3 mA
CC = 2 x 10-3 + 5 mA
Fixed output: 10 mV
Ripple and noise:
Two adjustable output:
CV = 0.5 mV rms
CV = 1.0 mV rms
CC < 3mA rms
Fixed output: 10 mV rms
Protection: Current-limit
Display accuracy:
Volt-indication: (0.2%Rdg+2 digits), 2.5% Full Scale
Amp-indication: (1.0%Rdg+2 digits), 2.5% Full Scale
Dimensions W. x H. x D.: 260 x 160 x 340
Weight: 10 kg
