* Optical Power Meter:Detector TypeInGaAs
Optical Connector:ST/SC/FC & 2.5mm Universal
Calibrated Wavelengths:850、1300、1310、1490、1550、1625 nm
Measurement Range:+6 ~ -70 dBm
Accuracy:± 0.2 dB
Power Measurement Linearity:±0.1 dB
Display Resolution:±0.01 dB
Power Display Units:dBm、mW、μW
* Visual Fault Locator:Output power:＜1mW
Range:3~5 kM @SM
Connector:ST/SC/FC & 2.5mm Universal
Laser safety rating:Class 2
Wavelength:650nm±20nm
Output modes:Continuous (CW) 、2 Hz pulsed
Reverse battery protection:Yes
* Lan Cable Tester:Connector:RJ45 & RJ11 shared
Cable:UTP LAN cable(8P8C)、Telecom cable(6P2C/6P4C/6P6C)
Measuring length Max.:600 meter
* Automatic Power Off:10 min.(Can be cancelled)
Low Battery Warning:Low battery energy
Battery Life:＞ 160 houre (only OPM)
Power source:AA/LR6 1.5V×2 pcs
Size:105×52×34 mm
