Measuring Range: 0.90 Ω to 1.00 x 10^12 Ω (with conductive rubber boots attached)
Contact Size: Electronic quality gold plated contact pins: 0.1” (2.54 mm) diameter Conductive synthetic rubber contact boots: 0.123” (3.12 mm) diameter
Outer distance between the 2 contact pins:
- without rubber boots attached: 0.325” (8.26mm)
- with rubber boots attached: 0.355” (9.02mm)
Outer diameter of the probe assembly: 0.49” (12.45mm)
Minimum Sample: Planar material: 0.125” (3.175mm) wide having a length of 0.325” (8.26mm)
Molded parts (3 dimensional): 0.491” (12.46mm) diameter
Probe Spring: Force/Test 1.5 lb (0.68 kg)
Probe Travel: 0.25” (6.4 mm) Self-limited
Connection: BNC with outer source and inner sense connections
Power: Fixture powered by resistance instruments
Dielectric Material: Black Delrin
Finish: Black anodized
Length:
6.75 inches (171 mm) without probe covers
8.25 inches (210 mm) with probe covers
Probe Diameter: 0.49 inches (12.45 mm)
Probe Cover Diameter: 0.60 inches (15.25 mm)
Weight: 2.0 oz (58g)
