Protek 606A Handheld Battery Quality Analyzer

- Impedance Measure:
+ Range: 3mΩ~300Ω (6Range); Accuracy: ±0.8%rdg±10dgts
+ Battery Pack Test voltage: Max DC/400V
- DC Voltage Measure: Range: 5V~500V (3Range); Accuracy: ±0.5%rdg±5dgts
- AC Voltage Measure: Range: 500V (1 range); Accuracy: ±0.75%rdg±5dgts (40Hz-500Hz)
- AC Ripple Voltage Measure: Range: 5V (1 Range); Accuracy: ±2.5%rdg±10dgts( Max 10kHz)
- DC/AC Current Measure: Range: 4A, 40A, 400A, 1000A; Accuracy: ±0.5%rdg±5dgts+CT Tolerance
- Temperature(NTC Sensor) Measure: Range: -10°C~100°C; Accuracy: ±1°C±2dgts
- Data Storage & Interface:
+ Internal Memory: 8MB (up to250String)
+ Bluetooth: E-mail sending, Data transfer with PC connection
- Power Source
+ Internal Battery: 7.4V/5.4(Li-ion)
+ External Adaptor: 12V/2.5A
+ Battery Time: Up to 8 hours
- Accessories
+ Standard products: Meter bar 1 SET, Manual, Buetooth connector,
Data interface CD 1 Copy, External Adaptor
+ Optional: Current Clamp Adapter(CT), Temperature sensor, Warranty Extension(Basic Warranty is 1 year)
- Weight & Dimension
+ Display: 4" Mono LCD
+ Size: 232mm(L)×192mm(W)×111mm(H)
+ Weight: 1.4kg (Including Battery)
