Physical
Dimensions: Nominal 195 mm H x 145 mm D (7.7 in x 5.7 in)
Weight: Nominal 1.2 kg (2.6 lbs)
Frequency: 24 GHz
Sensor Body Material: PVDF main body, Valox 357 on cap and submersion shield
Mounting Connection: Rear: 1-inch BSP or NPT thread with BReezTM adapter. Optional mounting bracket available.
Cable: 5-core screened
Cable Lengths: Standard: 10 m, 20 m, or 30 m (32.8 ft, 65.6 ft, or 98.4 ft)
Optional: 50 m or 100 m (164 ft or 328 ft)
Maximum Separation: Up to 500 m (1,640 ft) from FarSight to controller or RTU/logger
Performance
Operational Range: Up to vertical height of 15 m (49 ft)
Technology: K-Band (ISM) Radar
Beam Angle: 10° inclusive
Velocity Range: ±0.2 m/s to ±6 m/s (±0.66 ft/s to ±19.7 ft/s) in most applications. Performance may vary depending on application.
Ideal surface condition would include visually observable ripples.
Accuracy: The greater of ±1.5% or 0.05 m/s (0.16 ft/s)
Max. Width of Measurement Area Per Sensor: Up to 3 m (9.8 ft)
Optimal Installation Angle: 30° to 50° (from horizontal) with built-in electronic tilt compensation
Environmental
Enclosure Protection: IP68 / NEMA 6P
Vibration Protection: Fully Potted
Ambient Operating Temperature: -40°C to +80°C (-40°F to +176°F)
Humidity: 0 to 99% (non-condensing)
Process Connection Temperature: -40°C to +80°C (-40°F to +176°F)
Power Suppy
Operating Voltage: 10 - 28 V DC
Power Consumption: 0.42 W
