Gain: 5 dBi
VSWR: 2
Style: Tilt/Swivel
Width: 36.7 mm
Length: 195 mm
Diameter: 13 mm
IP Rating: IP20
Impedance: 50 Ohms
Application: Wireless Networks
Unit Weight: 29.200 g
Polarization: Vertical
Mounting Style: Panel Mount
Electrical Type: Dipole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
