Gain: 16.5 dB
Technology: SiGe
Unit Weight: 295.367 mg
Mounting Style: SMD/SMT
Test Frequency: 1.575 GHz
Input Return Loss: 10 dB
NF - Noise Figure: 2.8 dB
Number of Channels: 1 Channel
Operating Frequency: 5 MHz to 4 GHz
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.7 V
Operating Supply Current: 10.5 mA
Operating Supply Voltage: 2.7 V to 3.6 V
P1dB - Compression Point: - 1.4 dBm
OIP3 - Third Order Intercept: - 8.5 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
