Gain: 4.88 dBi
VSWR: 3
Style: I-Bar Flex
Width: 13 mm
Height: 0.13 mm
Length: 49 mm
Impedance: 50 Ohms
Cable Type: 193 mm RF1.13
Application: Cellular Radio, Wireless Applications
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 1575 MHz, 1602 MHz, 1621 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2500 MHz, 3500 MHz, 4500 MHz, 5500 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 6 GHz
Minimum Frequency: 1.5 GHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF4
Protocol - GPS, GLONASS: BEIDOU, GLONASS, GNSS, GPS
Protocol - WiFi - 802.11: WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
