Camera Probe:
Camera Lens: CMOS
Resolution: 1280*720
Viewing Angle: 35°
Camera Focal Distance: 2MM
Depth of Field (DOF): 0MM~5MM
Front View Light Source: 6 LEDs for 10MM Irradiation Distance
Side View Light Source: /
Camera Probe Outer Diameter: 5.5MM
Insertion Length: 60cm
Camera Part Length: 49MM
Waterproof Level: IP67 (Probe Only)
TFT Display:
Size (Active area): 5 inch
Resolution: 800*480
Luminance for LCM: 500
Image Zoom: 1~3 times (1.0X, 1.5X, 2.0X)
Image Flip: 180° flip
Image/Video:
Image/Video Resolution: 1280*720
Signal Format: Digital
Image Format: .JPG
Video Format: .AVI
Internal Memory: Micro SD card (support Max. 32G)
Power Supply:
Working Voltage: 5V
Working Current: 460mA
Li-battery Capacity: 3800mAh
Charging Hour: about 5 Hours
Work Time:
Continuous working time: about 5 Hours
Working Temperature:
Working Temperature: -20°~45°
Packing
All the inspection camera kit is standard packed with tool case except the 89 series with economical packing by paper box as standard and tool case optional. Special requirements should be mentioned in order.
APPLICATIONS
The barrel borescope with the mirror is specially for barrel inspection, it can be used to:
* Inspect new and used guns before purchasing
* Check that bore has been properly cleaned
* Check for wear on the bore
* Identify areas of fouling in the barrel
* Inspect barrels for defects
* Inspect insides of cases, lug recesses, etc.
Notice:All graphics and specifications are subjuct to minor change without prior Notice. All rights reserved.
