Metrological parameters:
E1 Calibration Range: -
E2 Calibration Range : -
F1 Calibration Range : 10 – 20 kg
F2 Calibration Range : 5 – 20 kg
M1 Calibration Range: 1 – 25 kg
M2 Calibration Range : 500 g – 25 kg
Maximum capacity [Max] : 25.5 kg
Readability [d] : 10 mg
Standard repeatability [5% Max] : 5 mg
Standard repeatability [Max] : 12 mg
Permissible repeatability : 15 mg
Eccentricity (tested load) : 1d / 2 mm
Electric compensation range : 0 – 25.5 kg
Stabilization time : 5 s
Adjustment: internal
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions : 302×252 mm
Weighing device dimensions : 370×280×150 mm
Controling device dimensions : 249×170×72 mm
Packaging dimensions : 520×520×280 mm
Net weight : 11.5 kg
Gross weight : 13.7 kg
Communication interface:
Communication interface: 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi, Hotspot
Environmental conditions:
Operating temperature : +10 – +40 °C
Operating temperature change rate: ±2 °C / 12 h
Relative humidity : 30% – 70%
Relative humidity change rate : ±10% / 4 h
