Metrological parameters:
E1 Calibration Range : 1 – 5 kg
E2 Calibration Range : 1 – 5 kg
F1 Calibration Range : 1 – 5 kg
F2 Calibration Range : 1 – 5 kg
Maximum capacity [Max] : 5.05 kg
Readability [d]: 0.01 mg
Standard repeatability [5% Max] : 15 µg
Standard repeatability [Max] : 20 µg
Permissible repeatability : 35 µg
Eccentricity (tested load) : —
Electric compensation range : -10 g – +50 g
Stabilization time : 30 s
Adjustment : external
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions: ø75 mm
Weighing device dimensions : 350×405×650 mm
Controling device dimensions: 249×170×72 mm
Anti-draft chamber dimensions : 660×470×700 mm
Packaging dimensions : 1000×900×685 mm
Net weight : 71 kg
Gross weight : 98 kg
Communication interface:
Communication interface : 2×USB-A, USB-C, HDMI, Ethernet,Wi-Fi, Hotspot
Electrical parameters:
Power supply : 100 – 240 V AC 50/60 Hz
Environmental conditions:
Operating temperature: +15 – +30 °C
Operating temperature change rate : ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity : 40% – 60%
Relative humidity change rate : ±5% / 12 h (3% / 4 h)
