Metrological parameters:
E1 Calibration Range : 5 – 20 kg
E2 Calibration Range : 1 – 20 kg
F1 Calibration Range : 1 – 20 kg
F2 Calibration Range : 1 – 20 kg
M1 Calibration Range: —
M2 Calibration Range : —
Maximum capacity [Max] : 20.5 kg
Readability [d] : 0.1 mg
Standard repeatability [5% Max] : 0.15 mg
Standard repeatability [Max]: 0.2 mg
Permissible repeatability : 0.3 mg
Eccentricity (tested load): 0 mg
Electric compensation range: -500 g – +500 g
Stabilization time: 30 s
Adjustment : external (500g)
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions : ø190 mm - self centering
Weighing device dimensions : 1150×770×1300 mm
Controling device dimensions : 249×170×72 mm
Packaging dimensions : 1150×770×1300 mm
Net weight : 235 kg
Gross weight: 352 kg
Communication interface:
Communication interface : 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi, Hotspot
Electrical parameters:
Power supply : 100 – 240 V AC 50/60 Hz
Environmental conditions:
Operating temperature : +15 – +30 °C
Operating temperature change rate: ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity: 40% – 60%
Relative humidity change rate : ±5% / 12 h (3% / 4 h)
