Metrological parameters:
E1 Calibration Range : 20 – 50 kg
E2 Calibration Range : 5 – 50 kg
F1 Calibration Range : 5 – 50 kg
F2 Calibration Range : 5 – 50 kg
M1 Calibration Range: -
M2 Calibration Range : -
Maximum capacity [Max] : 51 kg
Readability [d] : 1 mg
Standard repeatability [5% Max] : —
Standard repeatability (load ≤ 20kg) : 1.5 mg
Standard repeatability [Max]: 2 mg
Permissible repeatability : 3 mg
Eccentricity (tested load): —
Electric compensation range: 0 g – 50.5 kg
Stabilization time: 30 s
Adjustment : external
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions : ø100 mm
Weighing device dimensions : 1050×650×1150 mm
Controling device dimensions : 249×170×72 mm
Packaging dimensions : 1770×900×1100 mm
Net weight : 260 kg
Gross weight: 380 kg
Communication interface:
Communication interface : 2×USB-A, USB-C, HDMI, Ethernet,Wi-Fi, Hotspot
Electrical parameters:
Power supply : 100 – 240 V AC 50/60 Hz
Environmental conditions:
Operating temperature : +15 – +30 °C
Operating temperature change rate: ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity: 40% – 60%
Relative humidity change rate : ±5% / 12 h (3% / 4 h)
