Metrological parameters
Maximum capacity [Max]: 4500 g
Minimum load: 500mg
Readability [d]: 10 mg
Verification unit [e]: 100mg
Tare range: - 4500 g
Standard repeatability [5% Max]: 5 mg
Standard repeatability [Max]: 8 mg
Standard minimum weight (USP): 10g
Standard minimum weight (U=1%, k=2): 1 g
Linearity: ±20 mg
Stabilization time:1.5 s
Adjustment: internal (automatic)
OIML Class: II
Physical parameters
Leveling system: manual
Display: 5″ graphic colour touchscreen
Delivery components: Balance, weighing pan, weighing pan shield, grounding bumper ×1, bumper ×3, power supply.
Weighing pan dimensions: 195×195 mm
Net weight: 4.33 kg
Gross weight: 5.5 kg
Protection class: IP 43
Touchfree operation: 2 IR Sensors
Communication interface
Communication interface: 2×RS232¹, USBA, USBB, Ethernet, WiFi®
Electrical parameters: Power supply
Adapter: 100 – 240V AC 50/60Hz 0.6A; 12V DC 1.2A
Balance: 12 – 15V DC 0.8A max
Power consumption: 4 W
Environmental conditions
Operating temperature: +10 — +40 °C
Ambient conditions monitoring (option): THBR 2.0 System, THBR BOX, THB P, THB W, THB S
Relative humidity: 40% — 80%
