Metrological parameters
-Maximum capacity [Max]: 6.1 g
-Minimum load: 0.1 mg
-Readability [d]: 1 µg
-Verification unit [e]: 1 mg
-Tare range: -6.1 g
-Standard repeatability [5% Max]:1,3 µ,g
-Standard repeatability [Max]: 3.5 µg
-Standard minimum weight (USP): 2.6 mg
-Standard minimum weight (U=1%, k=2): 0,26 mg
-Permissible repeatability [5% Max]: 2 µg
-Permissible repeatability [Max]: 5 µg
-Linearity: ±9 µg
-Eccentric load deviation: 7 µg
-Sensitivity time drift: 1×10⁻⁶/Year×Rt
-Stabilization time: ~3.5s
-Adjustment: internal (automatic)
-OIML Class: I
Physical parameters
-Leveling system: automatic - Reflex Level System
-Display: 10″ graphic colour touchscreen
- Weighing chamber doors: automatic
-Weighing pan dimensions: ø30 mm + 2× intended for stents
- Net weight: 14.5 kg
- Gross weight: 22.5 kg
- Protection class: IP 43
Communication interface
-Communication interface: 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot
-Electrical parameters: Power supply
- Adapter: 100 – 240V AC 50/60Hz 1A; 15V DC 2.4A
- Balance: 12 – 15V DC 1.4A max*
Environmental conditions
-Operating temperature: +10 — +40 °C
-Operating temperature change rate: ±0.3°C/1h (±1°C/8h)
- Relative humidity: 40% — 80%
- Relative humidity change rate: ±1%/h (±4%/8h)
