Width: 26.035 mm
Height: 25.654 mm
Length: 26.035 mm
Coil Type: Non-Latching
Unit Weight: 86.252 g
Coil Voltage: 28 VDC
Contact Form: 4PDT (4 Form C)
Mounting Style: Through Hole
Coil Resistance: 290 Ohms
Coil Termination: Solder Pin
Contact Material: Silver Cadmium Oxide (AgCdO)
Switching Voltage: 115 VAC, 28 VDC
Relay Contact Form: 4 Form C (4PDT-NO, NC)
Contact Termination: Solder Pin
Contact Current Rating: 10 A
