Width: 24.35 mm
Height: 17.4 mm
Length: 38.25 mm
Industry: Industrial
Approvals: EN60335-1, UL60950-1
Compliance: CAN/CSA; EAC; ERP; IEC; RoHS; UL
Dimensions: 38.25 mm x 24.35 mm x 17.4 mm
Efficiency: 78%
Unit Weight: 29 g
Output Power: 3 W
Input Voltage: 100 VAC to 277 VAC
Mounting Style: Wire Leads
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 277 VAC
Input Voltage - Min: 100 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 250 mA
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
