Width: 25.4 mm
Height: 16.5 mm
Length: 25.4 mm
Industry: Industrial
Approvals: UL/IEC/EN60950-1, UL/IEC/EN62368-1
Compliance: CAN/CSA; CE; EAC; ERP; IEC; RoHS; UL
Efficiency: 80%
Unit Weight: 20 g
Output Power: 5 W
Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 85 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 1 A
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 50 C
Minimum Operating Temperature: - 25 C
