Width: 51 mm
Height: 24.5 mm
Length: 53 mm
Industry: Medical
Approvals: IEC/EN60335-1, IEC/EN60950-1, IEC/EN61558-2-16, UL60601-1, UL60950-1
IP Rating: IP68
Compliance: ANSI; CAN/CSA; CE; EAC; ERP; FCC; IEC; RoHS; UL
Efficiency: 83.5%
Unit Weight: 92 g
Output Power: 18 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Wire Leads
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4.6 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 750 mA
Output Voltage-Channel 1: 24 VDC
Maximum Operating Temperature: + 50 C
Minimum Operating Temperature: - 25 C
