Width: 20.3 mm (0.799 in)
Height: 10.2 mm (0.402 in)
Length: 31.8 mm (1.252 in)
Industry: Medical
Compliance: ANSI; CB; CAN/CSA; EAC; ERP; IEC; REACH; RoHS; UL
Efficiency: 84%
Unit Weight: 14 g
Output Power: 5 W
Input Voltage: 36 V to 75 V
Mounting Style: Through Hole
Isolation Voltage: 8 kV
Number of Outputs: 2 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 36 V
Input Voltage, Nominal: 48 V
Output Current-Channel 1: 166 mA
Output Current-Channel 2: 166 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
