Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Unit Weight: 2.800 g
Output Power: 1 W
Input Voltage: 22.8 V to 25.2 V
Mounting Style: Through Hole
Isolation Voltage: 1 kV
Number of Outputs: 2 Output
Input Voltage - Max: 25.2 V
Input Voltage - Min: 22.8 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 42 mA
Output Current-Channel 2: 42 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
