Measuring Range: 0.1μΩ～110MΩ
Test Accuracy: 0.02%
Maximum Test Current: 1A
Display
Display: 24 Bit Color, Resolution 480 * 272 True Color IPS LCD
Number Of Readings: Five Half Digit Display Resistance Value
Measuring Function
Resistance Measurement Time
Fast Speed: 7ms
Medium Speed: 42ms
Slow Speed / Precise Measurement: 150ms (Turn On The Above Display Plus 15ms)
Elimination Of Thermoelectric Potential:√
Test Side Configuration: Four Terminal
Statistical Function: Quantity Statistics Of Upper / Lower Qualified Products
Save Test Parameters: 10 Groups
Low Voltage Measurement: Open Circuit Voltage: ≤ 60mV, Effective Range: 2 Ω ~ 20 Ω
Poor Contact Detection: Check For Poor Contact At The Test End
Temperature Measurement
Measurement Parameters: PT1000: Accuracy 0.1 ℃
Display Range: -10℃-99.9℃
Comparator
Signal Output:HI/PASS1-PASS2/LO/FAIL
Sound Of News: Pass / Fail / Close
Limit Setting Mode: 14 Gears; Absolute Value Upper / Lower Limit; Percentage Upper / Lower Limit + Nominal Value
Other Parameters
Interface: USB HOST/USB DEVICE/RS232/HANDLER/RS485
Working Environment: Temperature 0 ℃～ 40 ℃ Humidity < 80% RH
Size: 361×107×264mm
Weight: 4kg
Accessories: Four Terminal Kelvin Test Clip, Temperature Probe, USB / 232 Communication Cable, Power Cable
