AC
Output voltage: 0～50kV
Test current: 0～2/20/40mA
DC
Output voltage: 0～50kV
Test current: 0～2/20mA
Test accuracy: ±(5%+3 characters)
Test time: 1～99s±1%
Transformer capacity: 2000VA
PLC interface: -
Power supply requirements: AC220V±10% 50Hz/60Hz
Working environment: Temperature: (0-40)℃ Humidity ≤75%RH
Appearance style: Seperate
Dimensions
(DxWxH):
⑴375*279*196mm
⑵695*475*835mm
Weight: ⑴12.05Kg ⑵63.14kg
Accessories: High voltage test wire, ground wire, power wire, high voltage discharge rod, connecting wire
Optional: RK101 Series Inspection Box
