Testing Functions
Test Parameters: |Z|,C,L,R, X, ESR,D,Q,Θ
Basic Precision: 0.05%
Testing Speed: Fast: 50, Medium: 10, Slow: 2.5 (Times / Sec)
Equivalent Circuit: Series Connection, Parallel Connection
Range Way: Auto, Hold
Trigger Mode: Internal, Manual, Automatic DUT, External, Bus
Correcting Feature: Open / Short Circuit Clearing
Display: 480*272,4.3-Inch TFT Color Screen
Memory: Internal 100 Groups, External U Disk 500 Groups
Test Signal
Test Frequency: 50Hz,60Hz,100Hz,120Hz,1kHz,10kHz
Output Impedance: 30Ω, 50Ω, 100Ω
Test Level: 50mV – 2.0V, Resolution:10mV
Measurement Display Range
Ls、Lp: 0.00001μH~99.9999kH
Cs、Cp: 0.00001pF~99.9999mF
R、Rs、Rp、X、Z: 0.00001Ω~99.9999MΩ
G、Y、B: -
ESR: 0.00001mΩ~99.9999kΩ
D: 0.00001~99.9999
Q: 0.00001~99999.9
Qr: -3.14159~3.14159
Qd: -180.000°~180.000°
D%: -99.9999%~999.999%
Comparators And Interfaces
Comparator: Grade 5 Sorting,BIN1 – BIN3,NG,AUX, PASS/FAIL LED Display
Interface: RS232C/USB-HOST/USB-CDC/ USB-TMC/HANDLER(Optional)
General Specifications
Working Temperature And Humidity: 0°C-40°C, ≤90%RH
Power Requirements:
Voltage:99V – 242V
Frequency:47.5Hz-63Hz
Power Waste: ≤ 20 VA
Size(W×H×D): 280mm×88mm×320mm
Weight: About 2.5 Kg
