number of units: 4 way independent unit
Pressure test
The output voltage
AC: 0.05kV～5.00kV ±(1%+5 characters)
DC: 0.05kV～6.00kV ±(1%+5 characters)
Setting error: ±(1%+5 characters)
Current test range
AC: 0～10mA ±(1%+5 characters)
DC: 0～5mA ±(1%+5 characters)
fast discharge: Automatic discharge after test (DCW)
Insulation resistance test
Output voltage (DC): 0.05kV～5.00kV ±1%
Resistance test range: ≥500V 0.2MΩ～1GΩ±(5%+5 characters) 1GΩ～50GΩ±(10%+5 characters) 50GΩ～100GΩ±(15%+5 characters) ＜500V 0.2MΩ～1GΩ±(10%+ 5 words) 1GΩ～10GΩ is for reference only, no precision requirement
Discharge function: Automatic discharge after the test is over
Arc Detection
Measuring range
AC: 1～20mA
DC: 1～20mA
General parameters
Voltage rise time: 0.1～999.9S
Test time setting (AC/DC): 0.2～999.9S OFF=Continuous test
Voltage fall time: 0.1～999.9S
time precision: ±1%+0.1S
interface: HANDLER interface, RS232C interface, RS485 interface, USB interface, U disk interface
Operating temperature: 10℃～40℃,≤90%RH
Power Requirements: 90～121V AC (60Hz) or 198～242V AC (50Hz)
Power consumption: <1000VA
Volume (D×H×W): 720mm×210mm×440mm
Weight (net weight): 43.3KG
Optional accessories: RK00031 USB to RS485 female serial cable industrial grade cable 1.5 meters long, host computer
Random standard accessories: Power cord RK00001, RS232 communication cable RK00002, RS232 to USB cable RK00003, USB to square port cable RK00006, 16G U disk (instruction manual), cable interface transfer driver CD, RK26003A test line, RK26003B test line, RK8N+ high voltage rod
