Pressure test
Output voltage (KV): AC: 0.05-5.00 DC: 0.05-6.00
Test accuracy: ±(2.0% setting +2V)
output precision: ±(2.0% setting +5V) no load
Test current (mA): AC: 0.001mA-20mA DC: 0.1uA-10mA
Test accuracy/ Setting error: ±(2.0% reading + 5 digits)
Insulation test
Output voltage (KV): DC: 0.05kV-5.0kV ±(1%+5 characters)
Test accuracy: ±(2.0% setting +2V)
Resistance test range: 0.1MΩ-100GΩ
Test accuracy:
≥500v
0.10MΩ-1.0GΩ ±5%
1.0G-50.0 GΩ ±10%
50.0 GΩ-100.0 GΩ±15%
<500V
0.10MΩ-1.0GΩ ±10%
1.0GΩ-10.0GΩ No precision requirement
Discharge function: Automatic discharge after the test is over
Arc Detection
Current measurement range: 1mA-20mA
testing time: 0.1S-999.9S
Output frequency: 50Hz/60Hz
Input characteristics: 115V/230V±10% 50Hz/60Hz
test alarm: Buzzer, LCD display, FAIL indicator
keyboard lock: Independent keyboard lock key
screen size: 5 inch TFT LCD
Communication Interface: HANDLER, RS232, RS485, USBDRV (computer interface), USBHOST (U disk interface)
Voltage rise time: 0.1S-999.9S
Test time setting (AC/DC): 0.2S-999.9S
Voltage fall time: 0.1S-999.9S
waiting time: 0.2S-999.9S
storage: 16M flash, each file can store 50 test steps
Dimensions (DxWxH): 450*350*122mm
weight: 15KG
Standard accessories: Test clip, ground clip, cross uncontrolled high voltage rod, power cord, RS232 serial port cable
Optional accessories (complete set): 16G U disk (including PC software), RS232 to USB cable, USB to square port cable, RK501 insulation check box, RK00031, RK101 series check box
