ACW
Output voltage range: 0.05~5kV
Maximum output power: 100VA（5kV 20mA）
Maximum rated current: 0.001mA-20mA
Output waveform: Sine wave DDS+ amplifier
DCW
Output voltage range: 0.05~6kV
Maximum output power: 60VA（6kV 10mA）
Maximum rated current: 0.1uA-10mA
IR
Output voltage (DC): 0.10~1kV
Resistance test range:
≥500V
1MΩ-1GΩ± (5% reading ±5 digits)
1GΩ-10GΩ± (10% reading ±5 digits)
<500V
0.1MΩ-1GΩ± (10% reading ±5 digits)
1GΩ-10GΩ For reference only, no accuracy requirement
GR
Output current: AC 3-30A
Current accuracy: ±(2.0% setting + 0.02A)
Resistance test range: 0-510mΩ, when the output current is 3-10A; 0-120mΩ, when the output current is 10-30A;
Resistance accuracy: ±(2.0% reading value + 1mΩ)
Timer
Range: 0.0-999.9S
Minimum resolution: 0.1S
Test time: 0.1S-999S OFF= continuous test
Arc detection: 0-20mA
Output frequency: 50Hz/60Hz
Operating temperature: 0-40℃ ≤75%RH
Power requirements: 110/220 ±10% 50Hz/60Hz ±3Hz
Interface: RS232, USB, PLC, RS485 as standard
Screen: 7-inch TFT 800*480
Dimensions (D*H*W): 440mm*135mm*485mm
Weight: 23KG
Standard accessories: High voltage test line, test loop line, ground test clip, cross-shaped uncontrolled high voltage test rod
Optional accessories (complete set): RS232 to USB cable, USB to square port cable, RK301 inspection box, RK501 insulation inspection box, RK101 withstand voltage, RK00070 serial port option LAN network port
