Width: 10 mm
Height: 4.5 mm
Length: 15 mm
Fall Time: 11 ns
Rise Time: 10 ns
Technology: Si
Channel Mode: Enhancement
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 56 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 25 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 30 ns
Typical Turn-Off Delay Time: 60 ns
Id - Continuous Drain Current: 70 A
Maximum Operating Temperature: + 150 C
Forward Transconductance - Min: 90 S
Rds On - Drain-Source Resistance: 6.7 mOhms
Vds - Drain-Source Breakdown Voltage: 75 V
Vgs th - Gate-Source Threshold Voltage: 4 V
