Bandwidth: 1X: DC to 35 MHz 10X: DC to 150 MHz
Rise Time: 1X: 10 ns 10X: 2.3 ns
Attenuation Ratio: 10:1 or 1:1 Switchable
Input Resistance:
1X: 1 MΩ ± 1% @ DC
10X: 10 MΩ ± 1% @ DC
Input Capacitance:
1X: 50 pF ± 20 pF
10X: 10 pF ± 5 pF
Max. Rated Input Voltage:
1X: 150 VRMS CAT II
10X: 300 VRMS CAT II
Compensation Range: 10 pF to 25 pF
Cable Length: 120 ± 2 cm
Probe Tip Diameter: 4.6 mm
Temperature: Operating: 0℃ to +50℃
Nonoperating: -20℃ to +70℃
Altitude: Operating: 2,000 m
Nonoperating: 15,000 m
Max. Relative Humidity: 80% relative humidity for temperature up to +31℃, decreasing linearly to 40% relative humidity at +50℃
Weight (probe only): About 40 g
