Width: 1.6 mm
Height: 0.85 mm
Length: 2.9 mm
Technology: Si
Unit Weight: 54.228 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 1 W
DC Current Gain hFE Max: 680 at 200 mA, 2 V
Gain Bandwidth Product fT: 200 MHz
Emitter- Base Voltage VEBO: 6 V
Collector- Base Voltage VCBO: 30 V
Maximum DC Collector Current: 3 A
Maximum Operating Temperature: + 150 C
DC Collector/Base Gain hfe Min: 270 at 200 mA, 2 V
Collector- Emitter Voltage VCEO Max: 30 V
Collector-Emitter Saturation Voltage: 250 mV
