Fall Time: 2.9 ns, 3.2 ns
Rise Time: 4.5 ns, 5.2 ns
Technology: Si
Unit Weight: 50.585 mg
Channel Mode: Enhancement
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 6 nC, 7.4 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8.2 ns, 8.4 ns
Typical Turn-Off Delay Time: 19.2 ns, 19.7 ns
Id - Continuous Drain Current: 10 A, 11 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 5 S, 6 S
Rds On - Drain-Source Resistance: 11.8 mOhms, 14.6 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
