Fall Time: 280 ns
Rise Time: 80 ns
Technology: Si
Unit Weight: 155.833 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 60 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 20 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 26 ns
Typical Turn-Off Delay Time: 300 ns
Id - Continuous Drain Current: 30 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 25 S
Rds On - Drain-Source Resistance: 6.7 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1.2 V
