Fall Time: 340 ns
Rise Time: 66 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 185 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 189 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 58 ns
Typical Turn-Off Delay Time: 250 ns
Id - Continuous Drain Current: 225 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 55 S
Rds On - Drain-Source Resistance: 2.2 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 4 V
