Rotronic TF53x Temperature Transmitters (-100 ~ 200 °C)

General

Parameter: Temperature

Housing material: ABS

Protection: IP65

Dimensions: 129 × 72 × 45 mm

Weight: 220 g

Probe connection: 4-pin Binder, threaded coupling

Display/Operation optional:

LCD, 1 or 2 decimals with backlight

Menu navigation, 4 keys

Electrical connections: Connections: screw terminals inside

Cable gland: M16

Power supply: 15…40 VDC / 12…28 VAC

Current consumption: <20 mA

Range of application / Storage conditions:

-40…60 °C / -10…60 °C (with LCD), 0…100 %rh

Temperature scaling: Max. -100…200 °C

Firmware update: Via HygroSoft software

Service interface: UART service interface (Universal Asynchronous Receiver Transmitter)

CE/EMC compatibility: EMC Directive 2014/30/EU

Fire protection class: Corresponds to UL94-HB

Analog output

Number: 1

Current: 0(4)…20 mA

Voltage: 0…1/5/10 V

Permissible load: ≤500 Ω (current output)

≥1 kΩ/V (voltage output)
