System: WINCE6.0
CPU: Main frequency 533MHz
Storage and RAM: RAM 256MB DDR2, 1GB Nand Flash
Display: 4.3" TFT true color LCD touch screen, resolution 480×272
Port: SD memory card, USB, serial ports, headphone
SD memory card: 8G and above TF card
Camera: 3 million pixel high-definition camera
Supplementary: GPS, thermo-hygrometer, high brightness laser pen
Storage function: GPS coordinate, time/date, temperature/humidity
Frequency: 20–150kHz
Sensor: 40kHz × 1Ea
Operating temp.: -25℃~70℃
Relative humidity: 0–95%
Power supply: Input 100–240V, 50/60Hz; Output: Voltage 16.8V, Current 1A
Battery: Lithium battery
Operating hours: ≈8 hours
Battery protection: LCD backlight turns off when there is no operation within 5 minutes. When the battery power is less than 5%, the system will beep to prompt saving data in time, and the user needs to shut down and charge.
Feature of the Testing Instrument:
1.Portable design, small size, light weight,
2.Accurate position and easy focus on faulty equipment through camera and laser detector.
3.Color touch screen, display waveform, dB value, temperature, humidity, GPS.
4. Convert the abnormal ultrasonic signal detected by the detector into audible sound signal and waveform output
5.The embedded GPS receiver automatically stores the coordinate data, which is convenient for querying and saving the detection path
6.Backstage data management software can realize data statistics and generate report.
7.High sensitivity, accurate position cable fault.
8.Free from noisy environment.
9.30 meters non-contact live detection distance, safe and reliable.
