Frequency Range 100 KHz-8.5 GHz
Frequency Resolution 1Hz
Test Port N type (F)
Measurement Point 1 - 16001
No. of Measurement Receiver 4
Reference Level Amplitude Setting
Range: ±500 dB; Resolution: 0.001 dB
Reference Phase Settings
Range: ±500 °; Resolution: 0.01 °
Measurement Fields Frequency domain and Time domain
Dimension (W x H x D) 435×233×348 mm
Weight 16 kg
Power Supply 50 Hz 220 V AC / 60 Hz 110 V AC
Interface N (F), 50Ω system impedance N (F), 75Ω system impedance (optional 001)
Operation Temp. 0 ℃ - ﹢40 ℃ (32 ℉ - 104 ℉)
Storage Temp. -20 ℃ - ﹢70 ℃ (-4 ℉-158 ℉)
Relative Humidity ≤ 90 %rh
