1. SA Mode
Frequency Range: 1kHz – 2GHz
Single Sideband Phase Noise:
-90dBc/Hz @ frequency offset 30kHz
-1100dBc/Hz @ frequency offset 1MHz
Maximum Input Level: +36dBm average continuous power, Maximum 50Vdc DC input voltage
DANL (pre-amplifier off): Frequency Conversion Channel:
100kHz – 1MHz: ≤-100dBm-30*(f/100kHz)dB
1MHz – 10MHz: ≤-130dBm
10MHz – 1GHz: ≤-135dBm
1GHz – 3.6GHz: ≤-140dBm
DANL (pre-amplifier on)
Frequency Conversion Channel:
100kHz – 1MHz: ≤-120dBm-30*(f/100kHz)dB
1MHz – 10MHz: ≤-150dBm
10MHz – 1GHz: ≤-155dBm
1GHz – 3.6GHz: ≤-148dBm
Low Frequency Channel:
5kHz – 10kHz: ≤-110dBm
10kHz – 10MHz: ≤-125dBm
Attenuator Range: 0 – 39dB, 3dB stepping
Detector: Automatic, normal, positive peak, negative peak, sampling
2. EMI Mode
Frequency Range: 1kHz – 2GHz
Resolution Bandwidth: 200Hz/9kHz/120kHz/1MHz (-6dB)
Detector: Positive peak, negative peak, Quasi-peak, average, RMS
Scan Time: 100us – 100s
Number of Traces: 3 (parallel detection)
Frequency Response: ±2.0dB
3. Tracking Source
Frequency Range: 10kHz – 1.5GHz
Output Power: -30dBm to 0dBm
Output Flatness: ±3dB
Display: 8.4 inch true color TFT-LCD
Communication Port: LAN, USB
Dimension: 280 (W) × 400 (L) × 190 (H) mm
Weight: 7.5kg
