Depth: 0.95 mm
Shape: Rectangular
Width: 1.85 mm
Length: 2.75 mm
Impedance: 300 Ohms
Port Type: Bottom
Tolerance: 1 dB
Dimensions: 2.75 mm x 1.85 mm x 0.95 mm
Output Type: Analog
Sensitivity: - 38 dB
Unit Weight: 20 mg
Mounting Style: SMD/SMT
Frequency Range: 100 Hz to 10 kHz
Termination Style: SMD/SMT
Sound Pressure Level: 130 dB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.6 V
Directional Properties: Omnidirectional
Operating Supply Current: 80 uA
Operating Supply Voltage: 2 V
SNR - Signal to Noise Ratio: 65 dBA
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
