Pitch: 2 mm (0.079 in)
Application: Elevated Board Staking
Stack Height: 3.05 mm
Current Rating: 5.2 A
Mounting Angle: Vertical
Mounting Style: Straight Pin
Number of Rows: 1 Row
Contact Plating: Tin
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Termination Post Length: 1.27 mm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
