I. Main technical characteristics
1. Full touch screen operation, convenient and fast.
2. 32-bit ARM microcontroller control, automatically control the water bath’s temperature, automatically collect, deal with dragging and force data.
3. Novel design of stretch drive, uniform speed, accurate display of ductility and force.
4. Shield type cold heat balance pressurization cycle system, to ensure the temperature in the bath is uniform.
5. Data storage, easy to query.
6. Automatically calculate and display average ductility value, max.force, elongation deformation value at maximum force and etc.
II.Main technical specifications
1. Power supply：AC（220±10%）V, 50Hz;
2. Measurement distance： 1.5m（±10mm）;
3. Heating mode：Electric heater;
4. Temperature control mode： Shield type cold heat balance pressurization cycle system;
5. Temperature control range： (5~50)℃, adjustable. Resolution is 0.01℃;
6. Temperature control accuracy： ±0.1℃;
7. Tensile speed： 10mm/min and 50mm/min, two grades;
8. Measurement accuracy： ±1 mm;
9. Ductility display： Display in real time;
10. Ductility record： By touching screen;
11. Force measurement： (0～300)N;
12. Force accuracy：±1N;
13. Data output：Real time display of industrial touch screen;
14. Refrigeration mode： Compressor refrigeration;
15. Ambient temperature： (15~+35)℃;
16. Relative humidity： ≤85%;
17. Dimension: 2365mm×530mm×950mm;
18. Total power consumption： ≤5600W;
