Feature & Use:
* Automatic testing process, no human operating error
* Large LCD screen, menu operating, complete function with data processing, hardness value conversion and so on
* Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10
It can be used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc. It is especially suitable to determine the Brinell hardness of soft metal materials and small parts.
Specifications:
Measuring range: 8-650HBW
Test force: 9.807, 49.03, 98.07, 153.2, 294.2, 612.9N (1, 5, 10, 15.625, 30, 62.5kgf)
Max. height of test piece: 180mm
Depth of throat: 125mm
Magnifications of measuring system: 125X, 50X
Min. scale value of the optical micrometer: 0.5μm
Power supply: 220/110V AC, 50 or 60Hz
Dimensions: 580 x 260 x 730mm
Weight: Approx. 90kg
Standard accessories:
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Tungsten carbide ball penetrator: Φ1, Φ2.5mm, 1 pc. each
Brinell standardized block: 2 pcs.
Printer: 1 pc.
