Measuring Angle: 20°/60°/85°
Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457
Measuring Area (mm): 20°: 10x10; 60°: 9x15; 85°: 5x36
Measuring Range: 20°:0~1000GU; 60°:0~1000GU; 85°：0~160GU
Division Value: 0.1GU
Measurement Range: 0-10GU; 10-100GU; 100-2000GU
Repeatability: ± 0.1GU; ± 0.2GU; ± 0.2%GU
Reproducibility: ± 0.2GU; ± 0.5GU; ± 0.5%GU
Measurement Standard: Conform with JJG696 first class glossmeter working requirement
Chromaticity Corresponding: Corresponding with CIE 1931(2°) under CIE C light source
Errors: ±1.5 , ± 1.5%
Measuring Time: 0.1s
Dimension: L*W*H : 160mm*75mm*90mm
Weight: 350g
Language: Chinese/English
Battery: 3200mAh Li-ion Battery ，>10000 times(within 8 hours)
Display: TFT 3.5 inch, capacitive touch screen
Interface: USB/RS-232
StorageBasic mode: 1000
Software: GQC6 Quality Control Software with QC report printing functions and more extended functions.
Operation Temperature: 0~40℃（32~104°F）
Storage Temperature: -20~50℃（-4~122°F）
Humidity: <85% relative humidity, no condensation
Standard Accessories: Power Adapter, USB cable, User Manual, CD (Including QC software), Calibration Plate
Optional Accessories: Miniature Printer
Note: The specifications are subject to change without notice.
