Measuring Angle: 20°; 60°; 85°
Measuring Area (mm): 20°: 0-2000GU
60°: 0-1000GU
85°: 0-160GU
Division Value: 0.1GU
Measuring Modes: Basic mode; Statistic mode; Continuous mode; QC mode
Measuring Time: 0.5S
Repeatability: 0~100GU: ±0.2GU; 100~2000GU : ±0.2%GU
Accurate: Conform with JJG696 first grade requirements of gloss meter
Auto Power-off Time: Within 30s-120s
Language: Chinese & English
Storage: 35000(Basic mode &Statistic mode : 1500; Continuous mode : 10000; QC mode: 10000)
Display: 2.3 inch white and black screen
Size: 160*52*84mm
Weight: About 300g
Power Supply: 1pc dry-cell battery(can measure 10000 times) or use USB Charge
Interface: USB & Bluetooth 2.1 version
PC Software: GQC6 QC software can printing testing report and with more extended functions
Operation Temperature Range: 0-40℃（32-104° F）
Storage Temperature Range: -20-50℃（-4-122° F）
Humidity Range: < 85% RH, without condensation
Standard Accessories: USB cable, user manual, calibration plate, QC software
Optional Accessories: Miniature printer
Notification: the technical parameter is only for reference
