Range (bar): -0.95~2 bar
Pressure media: Air
Pressure pump: HP-04
Pressure Port: 1/4'' & 3/8'' BSP Female
Pump dimension in mm (Appox.): 170 x 45 (Height x Dia)
Pump weight (gms) (Appox.): 700
Resolution (bar): 6 digit user selectable
Instrument Port: ¼’’ BSP Male x 10 mm long
Instrument dimension: 100 x 100 x 55 (W x H x D) mm
Instrument weight: 400gms (Appox.)
Stability time: 1 to 2 mins
Accuracy: ± 0.05%FS
Display: 128 x 64 COG Graphic LCD with White LED Back light
Pressure units * (selectable): bar, mbar, Mpa, kpa, kg/cm², inHg, cmHg, mmHg, mH2o, ftH2o,inH2o, cmH2o, mmH2o
Pressure zero: One touch zero provided on front key
Pressure peak: Maximum &minimum with user reset option
Pressure overflow: FS X 2 (Max.)
Pressure burst: FS X 3 (Max.)
Temp. Measure: RTD -PT 100 (2, 3, 4, wire selectable)
Temp. Range: -199.999 ~ 850.000mA
Measure: 0-24 mA (scalable)
Display scale: -99999 ~ 99999 counts (for mA measure input)
Switch test: Provided
Display Hold: One touch hold provided on front key
Power supply: 9V DC ±5% / 200mAh Rechargeable battery with battery life 4 hours without back light ( or) 9V DC adapter /230V AC supply operated
PC Interface: RS 485
PC Software: Windows based semi-automatic calibration software (optional)
