Flash range: 30 – 300000 FPM (flash per minute), 0.5 – 5000 Hz
Accuracy: ±0.02 %, (±1 digit)
Resolution: 0.1 (30 – 999 FPM), 1 (1000 – 300000 FPM)
Light intensity: 1500 Lux at 20 cm distance and 6000 FPM
Flash duration: Adjustable
Flash color: Approx. 6500 K
Display: LCD multiline
Power supply: 3 x AA battery (Standard) or 3 x NiMH Accumulators – AA
Operating time (depending on frequency): Battery approx. 6 h, accumulator min. 6 h at 6000 FPM respectively
Air humidity: 95 % RH, max.
Housing material: Aluminium / ABS with shock absorber
Dimensions: 191 x 82 x 60 mm (LxWxH)
Weight net (gross): Approx. 420 g (850 g)
Trigger Input Principle: Optocoupler, isolated
Low level: < 1 V
Level: 3 – 32 V, NPN + PNP
Minimum pulse length: 50 µs
Reverse voltage protection: Yes
Trigger Output Principle: Short-circuit and overvoltage proof transistor output to the optocoupler, non isolated
Level: NPN, max. 32 V
Puls length: Adjustable
Maximum current: 50 mA
Reverse voltage protection: Yes
